Programming
84 Operating Instructions 867 - 04.0 - 03/2018
Information
At the factory, the knee button was assigned the switchable sewing
foot stroke function in push-to-run and hold-to-run mode ( p. 59).
The knee button (2) can also be assigned different functions.
To assign a function to the knee button (2):
1. Press the button.
2. Set the toggle switch (1) to the desired position (1 or 0).
If the toggle switch (1) is, for instance, set to the bottom
position, the new function is saved to the 0 position.
3. Keep the knee button (2) pressed for a few seconds.
flashes.
The display shows a numerical value (parameter t 5120).
4. Use the buttons + or - to set the numerical value to the desired
value associated with the new function ( Parameter list 867).
5. Confirm with
.
5.2 Control panel V810
Follow the Operating Instructions of the manufacturer.
5.3 Control panel V820
Follow the Operating Instructions of the manufacturer.
