Technical data
Operating Instructions 867 - 04.0 - 03/2018 149
11 Technical data
11.1 Noise emission
Workplace-specific emission value as per DIN EN ISO 10821:
L
pA
= 79 dB (A); K
pA
= ± 0.64 dB (A) at
• Stitch length: 6.0 mm
• Alternating sewing foot stroke 1.5 mm
• Speed: 2200 rpm
• Sewing material: 4-layer material G1 DIN 23328
11.2 Data overview by subclassses
1-needle machines with large hook (L)
Subclasses: 867-
-160122
-190020 ECO
-190122
-190125
-190322
-190425
-160426
Type of stitches Double lockstitch 301
Hook type Vertical hook, large (L)
Number of needles 1
Needle system 134-35
Maximum needle strength [Nm] 130 180
Maximum sewing thread size 120/3-
30/3
80/3-10/3
(up to 15/3 with short thread cutter)
Stitch length, forwards /
backwards [mm]
7/7 12/12
Number of adjustable stitch
lengths
12
Maximum s.p.m. 3800
Number of stitches on delivery 3400 3000 3400
