DURKOPP ADLER 867 Durkopp Adler

Maintenance
88 Operating Instructions 867 - 04.0 - 03/2018
6.2 Cleaning the motor fan mesh
Fig. 47: Cleaning the motor fan mesh
WARNING
Risk of injury from flying particles!
Flying particles can enter the eyes, causing injury.
Wear safety goggles.
Hold the compressed air gun so that the particles
do not fly close to people.
Make sure no particles fly into the oil pan.
NOTICE
Property damage from soiling!
Lint and thread remnants can impair the operation of the
machine.
Clean the motor fan mesh as described.
When sewing very fluffy material, clean the machine at
shorted intervals than every 160 hours.
(1) - Tabletop (2) - Motor fan mesh
①
②

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
