Operation

Operating Instructions 867 - 04.0 - 03/2018 59

4.13.3 Quick stroke adjustment via knee button

The increased sewing foot stroke can be activated using the knee

lever (2).

The toggle switch (1) on the rear side of the knee button (2)

determines whether the increased sewing foot stroke is switched

on permanently or only while the knee button (2) is pressed.

Fig. 30: Quick stroke adjustment via knee button

(1) - Toggle switch (2) - Knee button

Position Function Description

0 Push-to-run

mode

• To activate the sewing foot stroke:

Press the knee button once.

To deactivate the sewing foot stroke:

Press the knee button one more time.

1 Hold-to-run

mode

The sewing foot stroke remains activated

for as long as you hold down the knee

button.

①

②
