DURKOPP ADLER 867 Durkopp Adler

Maintenance
Operating Instructions 867 - 04.0 - 03/2018 95
5. Tighten the drain screw (3).
6. Connect the machine to the compressed air supply.
6.4.3 Cleaning the filter element
Fig. 51: Cleaning the filter element
To clean the filter element:
1. Disconnect the machine from the compressed air supply.
2. Drain the water condensation ( p. 94).
3. Loosen the water separator (2).
4. Loosen the filter element (1).
5. Blow out the filter element (1) using a compressed air gun.
6. Wash out the filter tray using benzine.
NOTICE
Damage to the paintwork from solvent-based cleaners!
Solvent-based cleaners damage the filter.
Use only solvent-free substances for washing out the filter
tray.
(1) - Filter element
(2) - Water separator
(3) - Drain screw
②
①
③

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
