Setup

128 Operating Instructions 867 - 04.0 - 03/2018

To assemble the compressed air maintenance unit:

1. Assemble the maintenance unit (3) to the upper cross bar (1)

of the stand using the bracket, screws and clip.

2. Connect the machine hose (4) coming out of the machine

head to the maintenance unit (3) at the top right.

3. Connect the system connection hose (2) to the pneumatic

system.

7.13.2 Setting the operating pressure

Proper setting

Refer to the Technical data ( p. 149) chapter for the permissi-

ble operating pressure. The operating pressure cannot deviate by

more than ± 0.5 bar.

NOTICE

Property damage from incorrect setting!

Incorrect operating pressure can result in damage to the

machine.

Ensure that the machine is only used when the operating

pressure is set correctly.
