DURKOPP ADLER 867 Durkopp Adler

Operation
Operating Instructions 867 - 04.0 - 03/2018 69
4.17 Switching needle bars on/off
On machines with switchable needle bars the needle bars can be
individually switched on and off via the L and R buttons.
Fig. 38: Switching needle bars on/off
To switch a needle bar off:
1. Press the button (1)/(2) for the desired needle bar.
 The button (1)/(2) lights up. The needle bar is switched off.
To switch a needle bar on:
1. Press the illuminated button (1)/(2).
 The button (1)/(2) turns off. The needle bar is switched on.
Information
You cannot switch off both needle bars at the same time. When a
needle bar is switched off and you press the button for the other
needle bar, this switches on the disabled needle bar so that both
needle bars are in use.
(1) - Button (left needle bar) (2) - Button (right needle bar)
②①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
