DURKOPP ADLER 867 Durkopp Adler

Operation
70 Operating Instructions 867 - 04.0 - 03/2018
4.18 Switching on and off the sewing lamp
Depending on its equipment, the machine may come with an
integrated sewing lamp that can be switched on and off.
The sewing lamp switches on and off independent of the main
switch.
Fig. 39: Switching on and off the sewing lamp
To switch on the sewing lamp:
1. Set the switch (5) to position I.
 The sewing lamp transformer is now powered on.
2. Set the switch (4) to position I.
3. Press the button (2).
 The sewing lamp illuminates.
4. Use the - (1) or + (3) button to set the brightness level.
To switch off the sewing lamp:
1. Press the button (2).
 The sewing lamp goes out.
2. Set the switch (4) to position 0.
(1) - Button -
(2) - Button
(3) - Button +
(4) - Switch
(5) - Switch
①
②
③
④
⑤

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
