DURKOPP ADLER 867 Durkopp Adler

Technical data
154 Operating Instructions 867 - 04.0 - 03/2018
Number of stitches on
delivery
3000 2500
Maximum fan height (*only
with reversing mechanism)
20 20* 20 20*
Maximum sewing foot
stroke
9
Positive operating
pressure [bar]
6
Air consumption [NL] 0.7 0.7
Length/width/height [mm]
1090/220/460
1390/
220/
460
Weight/with direct drive
[kg]
85/89 95/99
Rated voltage [V, Hz] Depends on the drive package
Rated power [W] Depends on the drive package
Subclasses: 867-
-190020-70 ECO -190040-70 ECO -190122-70 -190322-70 -190342-70 -290020-70 ECO -290040-70 ECO -290122-70 -290322-70 -290342-70 -290342-100

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
