DURKOPP ADLER 867 - Threading the Needle Thread; In 1-Needle Machines

Operation
Operating Instructions 867 - 04.0 - 03/2018 27
4.5 Threading the needle thread
4.5.1 In 1-needle machines
Fig. 7: In 1-needle machines (1)
WARNING
Risk of injury from moving, cutting or sharp
parts!
Crushing, cutting and punctures are possible.
Switch off the machine before threading the
needle thread.
Do not reach under the needle.
(1) - Thread guide
(2) - Spring tip
(3) - Tightening lever
(4) - Thread tension spring
(5) - Thread guide
(6) - Main tensioner
(7) - Additional tensioner
(8) - Pre-tensioner
(9) - Thread guide
+
1234
+
–
+
–
+
–
+
–
5
6
4
+
①
⑨
⑧
⑦
⑥
⑤
②③④
