DURKOPP ADLER 867 Durkopp Adler

Programming
Operating Instructions 867 - 04.0 - 03/2018 77
5 Programming
The machine comes with one of the following control panels
depending on its equipment:
• OP1000
•V810
•V820
5.1 Control panel OP1000
Fig. 42: Control panel OP1000
All software settings are performed using the OP1000 control panel.
The control panel is composed of a display and buttons.
Using the control panel you can:
• Use groups of buttons to select machine functions
• Read service and error messages
(1) - Control panel OP1000
①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
