DURKOPP ADLER 867 Durkopp Adler

Programming
82 Operating Instructions 867 - 04.0 - 03/2018
5.1.2 Assigning functions to buttons on the push
button panel
Fig. 44: Assigning functions to buttons on the push button panel
The buttons on the push button panel can be assigned different
functions. Possible function assignments are:
• Suppress start/end bartack
• Start/end bartack
• Single stitch
• Needle up/down
• Edge cutting
• Stroke adjustment
Seam program button group
Seam program I • Activates seam
program I
Seam program II • Activates seam
program II
Seam program III • Sets seam
program III
Button Function
+
+/–
+/–

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
