Operation
62 Operating Instructions 867 - 04.0 - 03/2018
4.14.2 Sewing with 2 stitch lengths
Fig. 33: Sewing with 2 stitch lengths
Depending on its subclass the machine is fitted with 2 adjusting
wheels for the adjustment of the stitch length. These can be used
to sew two different stitch lengths and can be activated with a
press of button (1).
The stitch lengths are set using the adjusting wheels (3) and (4).
NOTICE
Property damage may occur!
Machine can be damaged if the adjusting wheels are forced.
The machine is designed in such a way that the stitch length
at the top adjusting wheel cannot be set to a lower level than
at the bottom adjusting wheel.
Do not attempt to force the top adjusting wheel to set a lower
stitch length than at the bottom adjusting wheel.
NOTICE
Property damage may occur!
Risk of breakage.
The stitch length at adjusting wheel (3) must NOT be greater
than the stitch length at adjusting wheel (4).
(1) - Button
(2) - Marking
(3) - Adjusting wheel
(4) - Adjusting wheel
0
1
2
4
3
5
6
7
8
9
10
11
12
0
1
2
4
3
5
6
7
8
9
10
11
12
mm
mm
MAX
MIN
+
+/–+/–
