DURKOPP ADLER 867 Durkopp Adler

Operation
24 Operating Instructions 867 - 04.0 - 03/2018
4.3.3 Machines with switchable needle bars
Fig. 5: Machines with switchable needle bars
To insert or change the needle(s) on a 2-needle machines with
switchable needle bars:
1. Turn the handwheel until the needle bars (1) have reached
the upper end position.
2. Loosen the screws (2) on both sides.
3. Pull each of the needles out towards the bottom.
4. Insert new needles on both sides.
Important
When inserting the needles, align them such that the grooves (3)
face away from each other. Each groove must point to the hook
that belongs to this needle.
5. Tighten the screws (2) on both sides.
(1) - Needle bars
(2) - Screws
(3) - Grooves
(4) - Hook
④
③
②①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
