DURKOPP ADLER 867 Durkopp Adler

Operation
Operating Instructions 867 - 04.0 - 03/2018 25
4.4 Feeding needle/hook thread
Fig. 6: Feeding needle/hook thread
To feed the needle/hook thread:
1. Fit the thread reel on the plate (2).
The unwinding bracket (1) must stand directly above the
thread reel holder (3).
WARNING
Risk of injury from moving, cutting or sharp
parts!
Crushing, cutting and punctures are possible.
Switch off the machine before feeding the needle/
hook thread.
(1) - Unwinding bracket
(2) - Plate
(3) - Thread reel holder
①
②
③

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
