DURKOPP ADLER 867 Durkopp Adler

Operation
20 Operating Instructions 867 - 04.0 - 03/2018
4.2 Switching on and off the machine
Regulating the power supply, the main switch (2) on the control
is used to switch the machine on or off.
Fig. 2: Switching on and off the machine
Switching on the machine
To switch on the machine:
1. Set the main switch (2) to position I.
 The power supply is switched on, and the indicator
lamps (1) and (3) are lit.
Switching off the machine
To switch off the machine:
1. Set the main switch (2) to position 0.
 The power supply is switched off, and the indicator
lamps (1) and (3) are no longer lit.
(1) - Indicator lamp
(2) - Main switch
(3) - Indicator lamp
+
–
①
③②

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
