DURKOPP ADLER 867 Durkopp Adler

Operation
Operating Instructions 867 - 04.0 - 03/2018 51
Information
When the largest thread quantity is required, the thread tension
spring must be pulled approx. 0.5 mm up from its lower end
position. This occurs when the needle thread loop passes the
maximum hook diameter.
4.10 Lifting the sewing feet
The machine offers different ways to lift the sewing feet depending
on its equipment:
• ECO machines: mechanically using the knee lever
• CLASSIC machines: electropneumatically using the pedal
4.10.1 Mechanical lifting with the knee lever
Fig. 25: Mechanical lifting with the knee lever
(1) - Knee lever
①

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
