Technical data
Operating Instructions 867 - 04.0 - 03/2018 153
** For 2-needle machines equipped with the DC1550-DA321G
and a motor assembled to the machine head, the maximum
possible speed is 3,000 rpm.
1 and 2-needle long arm machines
Weight/with direct drive [kg] 55/59
Rated voltage [V, Hz] 230, 50/60
Rated power [kVA] 0.75
Subclasses: 867-
-260122
-290020 ECO
-290040 ECO
-290122
-290142
-290322
-290342
-290445
-490322
Subclasses: 867-
-190020-70 ECO
-190040-70 ECO
-190122-70
-190322-70
-190342-70
-290020-70 ECO
-290040-70 ECO
-290122-70
-290322-70
-290342-70
-290342-100
Type of stitches Double lockstitch 301
Vertical hook, large (L) x x x x
Vertical hook, extra-large
(XXL)
xxx x
Number of needles 1
2
Needle system 134-35
Maximum needle strength
[Nm]
180
Maximum sewing thread
thickness
80/3-10/3
Stitch length
Forwards/backwards [mm]
12/12
Number of adjustable
stitch lengths
121 2
Maximum s.p.m. 3000 2500
