DURKOPP ADLER 867 Durkopp Adler

Maintenance
Operating Instructions 867 - 04.0 - 03/2018 87
Fig. 46: Cleaning the machine
The following areas are particularly susceptible to soiling:
• Cutter on the winder (4)
• Area under the throat plate (1)
• Hook (3)
• Area around the needle (2)
To clean the machine:
1. Switch off the machine ( p. 20).
2. Remove any lint and thread remnants using a compressed
air gun or a brush.
NOTICE
Property damage from solvent-based cleaners!
Solvent-based cleaners will damage paintwork.
Use only solvent-free substances for cleaning.
(1) - Area under the throat plate
(2) - Area around the needle
(3) - Hook
(4) - Cutter on the winder
①
②
④
③

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
