DURKOPP ADLER 867 Durkopp Adler

Setup
Operating Instructions 867 - 04.0 - 03/2018 131
Required oil:
Only DA 10 or equivalent oil should be used for the machine, which
has the following properties:
• Viscosity at 40 °C: 10 mm²/s
• Flash point: 150 °C
CAUTION
Risk of environmental damage from oil!
Oil is a pollutant and must not enter the sewage
system or the soil.
Collect waste oil carefully and dispose of it and
oily machine parts in accordance with the
applicable statutory regulations.
NOTICE
Machine damage possible due to incorrect oil!
An incorrect oil type can cause damage to the machine.
Only use oil specified in the operating instructions.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
