DURKOPP ADLER 867 Durkopp Adler

Technical data
166 Operating Instructions 867 - 04.0 - 03/2018
1-needle machines with integrated motor and large hook (L)
Subclasses: 867-
-190020-M ECO -190122-M -190125-M -190322-M -190425-M -160122-M -190426-M
Stitch
length 0-6
Stroke 1-3 3000 3800 3800 3800 3800 3800 3800
Stroke 4 3000 3100 3100 3100 3100 3100 3100
Stroke 5 2500 2500 2500 2500 2500 2500 2500
Stroke 6-9 1800 1800 1800 1800 1800 1800 1800
Stitch
length 6-9
Stroke 1-4 3000 3000 3000 3000 3000 3800 3000
Stroke 5 2500 2500 2500 2500 2500 3100 2500
Stroke 6-9 1800 1800 1800 1800 1800 2500 1800
Stitch
length 9-12
Stroke 1-5 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
