Technical data
Operating Instructions 867 - 04.0 - 03/2018 169
1-needle long arm machines with integrated motor (-M)
Subclasses: 867-
-190020-70-M ECO -190040-70-M ECO
-190122-70-M -190322-70-M -190342-70-M -190142-70-M
Stitch
length 0-6
Stroke 1-3 3000 3000 3000 3000 3000 3000
Stroke 4 2800 2800 2800 2800 2800 2800
Stroke 5 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800
Stitch
length 6-9
Stroke 1-3 3000 3000 3000 3000 3000 3000
Stroke 4 2800 2800 2800 2800 2800 2800
Stroke 5 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800
Stitch
length 9-12
Stroke 1-5 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
