U60 Diagnostic Ultrasound System User Manual System Control
- 37 -
43.
F5
F5
Press to decrease brightness. And the brightness
symbol will be displayed at the bottom of the screen.
44.
F6
F6
Press to increase brightness. And the brightness
symbol will be displayed at the bottom of the screen.
45.
F7
F7
Press to decrease the volume in the PW mode. And
the volume symbol will be displayed at the bottom of
the screen
46.
F8
F8
Press to increase the volume in the PW mode. And the
volume symbol will be displayed at the bottom of the
screen
47.
F9
F9
Sound muting key
Press this to close the loudspeaker in the PW mode.
And the mute symbol will be displayed at the bottom of
the screen
Table 5-2 Function Controls
Menu Controls:
The 6 menu controls on the control panel correspond to items in the menu controls field. The
currently available items are highlighted, and unavailable items are in gray color; they also
correspond to items on the system menu in different modes or status, such as the image menu,
preset menu, file menu, needle guide menu, Cine Review menu, measurement menu, etc. You can
press or rotate the menu control, or use the trackball and Set in the menu field to switch/adjust
parameters, or activate a function.
Operations of menu controls:
 To switch options/adjust parameters:
If an item of the menu has a submenu or several parameter values, press or rotate the
menu control to switch between options or adjust values. (You can adjust values
circularly by pressing menu controls, rather than by rotating them).
For example, in File menu, press or rotate the FileType menu control to switch the image
format before saving it; in B mode, press or rotate the Dyn Rng menu control to increase
or decrease the value of dynamic range.
 To activate a function:
(1) If an item of the menu has a submenu or several options, rotate the menu control to
select submenu items or options, and press the menu control to activate the function.
For example, in B-generic measurement menu, rotate Volume menu control to select
2-Axis/3-Axis/3-Axis (LWH), and press the menu control to activate the option.
(2) If an item of the menu has no submenu or option, press the menu control to activate
the function directly.
For example, in File menu, press File Manager menu control to display the File
Manager dialog box directly.
