U60 Diagnostic Ultrasound System User Manual System Control
- 50 -
sleep mode (5-60 min), then
screensaver is displayed and acoustic
output is disabled.
Set the grade of refresh speed during
system dormancy.
Green/ Yellow/ White/ Red/ Orange
Set the color of the comment when
entering comments.
Green/ Yellow/ White/ Red/ Orange
Set the color of the comment when
comments are already saved.
Green/ Yellow/ White/ Red/ Orange
Set the color of the needle guide line.
Select the types of thermal index.
Set the brightness of monitor
Set the tones of monitor color
Set the output video mode
Set the output video color
Set the video printer paper size.
SONY_UP-D25MD
SONY_UP-DX898MD
Select the same video printer as that
you connect with the system via the
USB cable.
HP Deskjet 1010 Series, HP DeskJet
1110 Series, HP Deskjet 1510 Series,
HP Deskjet 2050 J510 Series, HP
Laserjet Pro 400 M401, etc
Select the same report printer as that
you connect with the system, or select
the report printer series that your printer
belongs to.
Note: The software supports all the
report printers in the report printer list,
but only the report printers
recommended in Section 3.2.2 are
tested. It is suggested to only use the
recommended printers.
None, Save Frame, Save Cine, Save
AVI, File Manager, Send DCM Image
(If DICOM is installed), Send Cine
Images(If DICOM is installed), Save
Preset Data, Needle guide,
Show/Hide menu, Sample line.
Define the F1/F2/F3/F4 keys, select one
of the pull-down options.
Set whether to only print images in the
report.
Table 5-3 System Preset Information
You must restart the system to validate the change, including Language and Keyboard Sound.
After you perform those presetting, and press OK, the system displays a confirm dialog box to
prompt you whether to restart the system.
