U60 Diagnostic Ultrasound System User Manual System Control
- 55 -
curve map
Rejection
0-7
Set the default rejection
Scan Mode
HiDen/HiFPS
Set the default scan mode
Depth
1.9 cm-32.4 cm（C5-2b）
Set the default examine depth
Scan Angle
0/1/2/3
Set the default scan angle
Pseudo Color
0-6
Set the default colorization colors
B/W Invert
On/Off
Set if the image is B/W inverted by default
90° Rotate
0/1/2/3
Set the default display direction of image
H Reverse
√/×
Set if image is inverted horizontally by
default or not
V Reverse
√/×
Set if image is inverted vertically by default
or not
Line Average
0-7
Set the default line average of M mode
Sweep Speed
0-3
Set the default sweeping speed of M mode
B/M Display
U/D, L/R
Set the default display layout of dual-split
mode B+M: Up/Down, Left/Right.
Table 5-4 B/M Mode Image Parameter Preset Information
Preset Items
Options
Functions
Flow Type
H Flow /M Flow/ L Flow
Set the default flow type
(high/ medium/ low speed)
Freq
F1/F2
Set the default frequency of probe in color
mode
Gain
1-80
Set the default gain of Color mode
PRF
0-15
Set the default PRF of Color mode
WallFilter
0-7
Set the default wallfilter of Color mode
Packet Size
4 levels, 8,10,12,14
Set the default packet size
Smooth filter
0-7
Set the default smooth filter
Persist
0-7
Set the default persist
Threshold
0-15
Set the default threshold
ROI Depth
Options for this parameter depend
on the depth range of each probe.
Set the default ROI depth of Color Mode
ROI Size
Small/Middle/Large
Set the default size of ROI of Color Mode
ROI Color
Yellow/Green
Set the default frame boundary color of ROI
Base Line
0~6
Set the default position of base line
Map
In Color mode:0-7
In PDI mode:
0-3 (PDI)
4-7 (DPDI)
Set the default map displayed in Color/PDI
mode
Steer
-10°、0°、10°
Set the steering angle of the ROI box. (Only
available for Linear transducers)
Table 5-5 Color/PDI Mode Image Parameter Preset Information
Preset Items
Options
Functions
Flow Type
H Flow /M Flow/ L Flow
Set the default flow type
(high/ medium/ low speed)
Freq
F1/F2
Set the default frequency of probe in PW
mode
Gain
1-80, in increments of 1
Set the default gain of PW image
