U60 Diagnostic Ultrasound System User Manual System Control
- 56 -
PRF
0-15, 0.9kHz-14.7kHz
Set the default PRF in PW mode
WallFilter
0-3
Set the default wallfilter in PW mode
Dyn Rng
30-90, in increments of 2
Set the default dynamic range of PW mode
Sample Volume
0.5-20.0
Set the default size of the sample volume
SV Depth
Options for this parameter depend
on the depth range of each probe.
Set the default depth of sample volume
Pseudo Color
0-6
Set the default colorization colors
Correction Angle
-79°-79°
Set the default correction angle
Sweep Speed
0-5
Set the default sweeping speed
Base Line
0-6
Set the default position of base line
Sound Volume
0-7
Set the default volume of Doppler
Steer
-10°、0°、10°
Set the steering angle of the sample line (for
linear array probes)
Duplex/Triplex
√/×
Set whether to scan in duplex/triplex mode
by default or not
Invert
√/×
Set the default direction of PW spectrum
（above/ below the base line）
HPRF
√/×
Set whether to turn on the HPRF mode by
default or not (this mode only works with
C5-2b, P5-1b and L15-7b probes)
Table 5-6 PW Mode Image Parameter Preset Information
Preset Items
Options
Functions
Flow Type
H Flow /M Flow/ L Flow
Set the default flow type
(high/ medium/ low speed)
Gain
1-80, in increments of 1
Set the default gain of CW image
Dyn Rng
30-90, in increments of 2
Set the default dynamic range of CW mode
PRF
0-31, 0.8kHz-80kHz
Set the default measurable range of flow
velocity
WallFilter
0-3
Set the default wallfilter in CW mode
Pseudo Color
0-6
Set the default colorization colors
Correction Angle
-79°-79°
Set the default correction angle
Sweep Speed
0-5
Set the default sweeping speed
Base Line
0-6
Set the default position of base line
Sound Volume
0-7
Set the default volume of Doppler
Invert
√/×
Set the default direction of CW spectrum
（above/ below the base line）
Table 5-7 CW Mode Image Parameter Preset Information
To set a default exam mode for a probe:
1. Select a probe and an exam mode in the Image Parameter Preset dialog box.
2. Roll the trackball onto the “Others” tab and press Set.
3. Select a default exam mode from the Default Image Mode pull-down menu.
4. Click on OK, a hint of “Are you sure you want to permanently save changes”pops out, click
Yes to confirm the setting, or click on Cancel to exit.
