9.8 HALF CYCLE CURRENT MONITORING
The EN1001 Series Controls may be used to weld using half of a cycle.
9.8.1 ENABLE HALF CYCLE WELDING
1. Put the control in PROGRAM mode.
2. Use the SELECT push button to find
EFEF
EFEF
EF.
3. Use the SCHEDULE push buttons to find
PP
PP
P
.O..O.
.O..O.
.O. in EXTENDED FUNCTIONS.
4. Program
PP
PP
P
.O..O.
.O..O.
.O.=
0909
0909
09 to enable HALF CYCLE welding.
5. Make sure the value for EXTENDED FUNCTION
S.E.S.E.
S.E.S.E.
S.E.=
0000
0000
00.
9.8.2 PROGRAM A HALF CYCLE WELD
1. Use the SCHEDULE push buttons to select a working schedule.
2. Program SQUEEZE to meet the cylinder squeeze requirements.
3. Program WELD=
0101
0101
01.
4. Program HOLD to meet the weld schedule requirements.
5. Program OFF=
0000
0000
00 (HALF CYCLE is not possible in REPEAT schedules).
6. Program IMPULSES=
0000
0000
00 (Many unidirectional HALF CYCLE IMPULSES induce
saturation/half cycling).
7. Program COOL=
0000
0000
00.
8. Program VALVE MODE to meet requirements of the machine.
9. Program CYCLE MODE=
0000
0000
00 (NON-REPEAT and non-CHAINED schedule).
10. Program SLOPE MODE=
0000
0000
00.
11. Program SLOPE COUNT=
0000
0000
00.
9.8.3 ENABLE CURRENT MONITORING
1. Use the SELECT push buttons and find
EFEF
EFEF
EF.
2. Use the SCHEDULE push buttons to find
C.rC.r
C.rC.r
C.r
..
..
. in EXTENDED FUNCTIONS.
3. Program
C.rC.r
C.rC.r
C.r
..
..
.=
11
11
1
11
11
1,
3131
3131
31, or
3333
3333
33, depending on the type of sensor used.
4. Program
rr
rr
r
.A..A.
.A..A.
.A. to proper range (see appropriate instructions in Section 5.4.16).
5. Use the SELECT push button to select PERCENT CURRENT.
6. Re-assert/update the programmed value by pressing ENTER or program the necessary
PERCENT CURRENT in the DATA display.
7. Put the control in OPERATE mode.
8. Make a weld. If necessary, adjust the CURRENT (repeat Steps 6, 7, and 8).
9. After the weld, the control will display a value of CURRENT.
10. Put the control in PROGRAM mode.
11. While in PERCENT CURRENT function, use the SCHEDULE push buttons to find
H.i.H.i.
H.i.H.i.
H.i. and
L.o.L.o.
L.o.L.o.
L.o. parameters.
12. Program the appropriate value of HIGH and LOW limits if necessary. If these values
are left at
0000
0000
00, control will use a limit of +10% for HIGH limit and -10% for LOW limit.
If FUNCTION indicator LEDs are set to display PERCENT CURRENT, the control will
show measured CURRENT after every weld. If the weld CURRENT is too low or too high,
the weld control will block further initiations. The Valve 3 output (410319 Firing Boards)
will turn on immediately upon a HIGH or LOW ERROR condition and remain on until the
Front Panel push buttons are used to acknowledge the error.
