SEAM Mode
S.E.S.E.
S.E.S.E.
S.E.=
0606
0606
06 – NON-BEAT SEAM
This mode was primarily designed as NON-BEAT SEAM mode, enabling execution of a fixed
time weld using a number of repetitions in addition to alternating two heats within single schedule.
The control is programmed as follows:
1. Use the SELECT push button until the DATA display shows
EFEF
EFEF
EF.
2. Use the SCHEDULE push buttons to find
S.E.S.E.
S.E.S.E.
S.E. in the SCHEDULE display.
3. Program a value
S.E.S.E.
S.E.S.E.
S.E.=
0606
0606
06 and press the ENTER push button.
4. Use the following information to program working schedule.
By definition, the SEAM mode is a BEAT mode operation. In a normal SEAM mode,
CHAINED mode of welding schedules is not available.
SQUEEZE count [normal SQUEEZE]
WELD/HEAT count [WELD 1] [normal WELD time]
PERCENT CURRENT [PERCENT 1] [normal PERCENT]
HOLD count [normal HOLD time]
OFF count [PERCENT 2] [new second PERCENT heat]
IMPULSES [Weld(1+2)*Factor] [repetition factor for overall WELD time]
COOL count [WELD 2] [new COOL will execute a second WELD/HEAT]
VALVE MODE [normal VALVE MODE]
CYCLE MODE [normal CYCLE MODE]
SLOPE MODE [normal SLOPE MODE]
SLOPE COUNT [normal SLOPE COUNT]
For
S.E.S.E.
S.E.S.E.
S.E. parameter, do not enter a value larger than
0606
0606
06
except when programming DELAY compensation (
S.E.S.E.
S.E.S.E.
S.E.=x
44
44
4).
5.4.3 SCHEDULE SELECT –
S.S.S.S.
S.S.S.S.
S.S.
The EN1000/EN1001 provides the user with 3 modes of SCHEDULE SELECT and/or initiation
– INTERNAL (panel-dialed), EXTERNAL (non-panel, FS7/FS11 select) and EXTERNAL
BINARY SELECT using S49 Option (50 non-panel, external schedules). The default (factory
settings) mode is INTERNAL SCHEDULE SELECT.
To program the control for desired SCHEDULE SELECT mode:
1. Put the control in PROGRAM mode.
2. Use SELECT to find
EFEF
EFEF
EF.
3. Use SCHEDULE push buttons to page through EXTENDED FUNCTIONS to find
S.S.S.S.
S.S.S.S.
S.S.
4. Enter a value for
S.S.S.S.
S.S.S.S.
S.S. of:
0000
0000
00,
0101
0101
01,
0202
0202
02, or
0303
0303
03 using the DATA push buttons.
Where:
S.S.S.S.
S.S.S.S.
S.S.=
0000
0000
00 for INTERNAL SCHEDULE SELECT (default)
S.S.S.S.
S.S.S.S.
S.S.=
0101
0101
01 for EXTERNAL SCHEDULE SELECT
S.S.S.S.
S.S.S.S.
S.S.=
0303
0303
03 for S49 EXTERNAL BINARY SCHEDULE SELECT
5. Press the ENTER push button.
5.4.2 SEAM WELDING MODE –
S.E.S.E.
S.E.S.E.
S.E. (cont.)
NOTICE


 CAUTION



