Page 96 • 700120S • ENTRON Controls, LLC.
7.5.3 STEPPER RESET USING EXTERNAL SWITCH INPUT
Since PROM firmware version 619016-002S, it is possible to use an External Reset switch
(normally closed) connected between TS1-ES1 and TS1-GND to cause STEPPER RESET. To
enable EXTERNAL RESET, EXTENDED FUNCTION
b.E.b.E.
b.E.b.E.
b.E. must be programmed to
0606
0606
06.
Whenever momentary switch is activated (open), control will automatically reset active stepper.
7.6 USING THE STEPPER AS A COUNTER
The stepper counter may be used as a down-counter. It is simply necessary to load a schedule
stepper counter with a value to count down from. The maximum allowable value is 9999. This
function may be used in a single weld schedule, such as 00, 10, 20, 30, or 40, or any welding
sequence starting with those schedules.
1. Select schedule to be used.
2. Put the control in PROGRAM mode.
3. Enable STEPPER by programming
S.t.S.t.
S.t.S.t.
S.t.=
0101
0101
01 or
0202
0202
02.
4. Program weld schedule as required.
5. Select WELD/HEAT parameter again.
6. Find
a.0a.0
a.0a.0
a.0,
b.0b.0
b.0b.0
b.0, etc., by pressing the right SCHEDULE push button.
7. Program desired COUNT from
00000000
00000000
0000 to
99999999
99999999
9999 in the DATA display and press ENTER.
8. Reset STEPPER by pushing ENTER and the two DATA push buttons simultaneously.
9. Put the control back in OPERATE mode.
If necessary, the message
S.t.S.t.
S.t.S.t.
S.t.
E.n.d.E.n.d.
E.n.d.E.n.d.
E.n.d. may be shown at the end of the countdown. Select the
next schedule and clear it by using the clear data shortcut (see Section 5.4.5). Program a
WELD time of 01 cycles and return to the OPERATE mode.
7.7 DISPLAYING THE STEPPER COUNT DURING OPERATION
The stepper count may be displayed during operation if necessary. Since this is not a principal
WELD function, the access to the display requires the following:
1. Select the schedule to be used.
2. Put the control in PROGRAM mode.
3. Select the WELD/HEAT parameter.
4. Find
L.C.L.C.
L.C.L.C.
L.C. by pressing the right SCHEDULE push button.
5. Put the control back in OPERATE mode.
The LAST COUNT will be shown after end of each welding sequence.
7.8 END OF STEPPER
When LAST STEP is reached, control will flash message
S.t.S.t.
S.t.S.t.
S.t.
E.n.d.E.n.d.
E.n.d.E.n.d.
E.n.d. on displays. This message
can be cleared by pressing any Front Panel push button or by activating Emergency Stop.
To avoid resetting the counter value, use the External Switch input (see Section 7.5.3).
If
PP
PP
P
.O..O.
.O..O.
.O. is programmed to
1010
1010
10 or
1717
1717
17, PROCESS OUTPUT valve or Valve 3 will be active as long as
message
S.t.S.t.
S.t.S.t.
S.t.
E.n.d.E.n.d.
E.n.d.E.n.d.
E.n.d. is flashing on displays.
NOTICE
