Entron EN1000 series

ENTRON Controls, LLC. • 700120S • Page 69
5.4.10 MANUAL POWER FACTOR PROGRAMMING –
PP
PP
P
.P.P
.P.P
.P
..
..
.
If required, the EN1000/EN1001 Control can be placed in the MANUAL POWER FACTOR
mode as follows:
1. Place the control in the PROGRAM mode.
2. Use SELECT and find
EFEF
EFEF
EF.
3. Use the SCHEDULE push buttons to find
PP
PP
P
.P.P
.P.P
.P
..
..
.
4. Use the DATA push buttons to enter the machine’s POWER FACTOR as measured
following steps outlined in Section 5.4.11.
Where:
PP
PP
P
.P.P
.P.P
.P
..
..
.=
0000
0000
00 The control in AUTOMATIC POWER FACTOR mode (default).
PP
PP
P
.P.P
.P.P
.P
..
..
.=[xx] If xx is not 00, the control is in MANUAL POWER FACTOR
mode and the programmed POWER FACTOR is xx.
5. Press ENTER.
When using the EN1001 Control in CONSTANT CURRENT mode, both AUTOMATIC
POWER FACTOR and CONSTANT CURRENT function will compensate current. When
the control operates under poor power factor and low PERCENT CURRENT output situation,
the MANUAL POWER FACTOR should be set to 99% (
PP
PP
P
.P.P
.P.P
.P
..
..
.=
9999
9999
99) to obtain better performance.
5.4.11 POWER FACTOR MEASURING –
PP
PP
P
.F.F
.F.F
.F
..
..
.
The EN1000/EN1001 Control is in the AUTOMATIC POWER FACTOR mode when shipped
from the factory. Calibration of the automatic power factor circuit is not required. This has two
benefits:
1. It is not necessary to make manual adjustments when installing the control, to match its
circuitry to the POWER FACTOR of the welding machine;
2. It assures that maximum welding current, for any welding transformer tap switch setting,
will occur when the selected PERCENT CURRENT is 99%.
If desired, for some applications, the AUTOMATIC mode can be disabled and the machine
POWER FACTOR can be set manually (see Section 5.4.10). Machine’s POWER FACTOR can
be determined when in the AUTOMATIC POWER FACTOR mode as follows:
1. Use SELECT to find
EFEF
EFEF
EF.
2. Use the SCHEDULE push buttons to find
PP
PP
P
.F.F
.F.F
.F
..
..
.
3. Make a weld.
At this point, after the weld is complete, the machine’s POWER FACTOR will be shown in the
DATA display (see Section 5.4.10).
When measuring the POWER FACTOR, the displayed POWER FACTOR corresponds to the
last weld made by the control.
NOTICE
NOTICE
