7.3 SEQUENCE (SCHEDULE) INITIATION IN STEPPER MODE
7.3.1 SCHEDULE SELECT OPTIONS FOR STEPPER MODE
S.t.S.t.
S.t.S.t.
S.t.=
0101
0101
01
Since the stepper requires certain specific starting schedules, the SCHEDULE SELECT (
S.S.S.S.
S.S.S.S.
S.S.)
options with STEPPER mode
0101
0101
01 are described in the following sections.
INTERNAL SCHEDULE SELECT –
S.S.S.S.
S.S.S.S.
S.S.=
0000
0000
00
As shown in Table 7-1, each of the five steppers can be initiated with the FS3 initiation switch.
This is possible only if any of the ten possible schedules for desired stepper is dialed on the
SCHEDULE display.
Besides FS3 initiation, steppers B and C can be initiated with FS7 and FS11 initiation switches.
FS7 is dedicated to initiate only stepper B (schedule 10 to 19) regardless of what schedule is
dialed on SCHEDULE display. FS11 is dedicated to initiate only stepper C (schedule 20 to 29)
regardless of what schedule is dialed on SCHEDULE display.
EXTERNAL SCHEDULE SELECT –
S.S.S.S.
S.S.S.S.
S.S.=
0101
0101
01
In this mode, only four steppers
can be initiated with the FS3
initiation switch. This is possible
only if FS7 and FS11 are used for
stepper selection, as shown in
Table 7-3.
EXTERNAL BINARY SELECT WITH S49 OPTION –
S.S.S.S.
S.S.S.S.
S.S.=
0303
0303
03
In this mode, any of five steppers
can be initiated with FS3
initiation switch. The stepper
selection is possible with closing
one of the SS1, SS2, SS4, or SS8.
7.3.2 SCHEDULE SELECT OPTIONS FOR STEPPER MODE
S.t.S.t.
S.t.S.t.
S.t.=
0202
0202
02
Stepper counter will be decremented only if FS3 is used for initiation.
When either FS7 or FS11 is used for initiation in STEPPER mode
0202
0202
02, stepper counter will not
be decremented, and control will execute the welding sequence starting with schedule 10 or 20,
respectively. But, when S49 Option is used for EXTERNAL BINARY SELECT (
S.S.S.S.
S.S.S.S.
S.S.=
0303
0303
03) after
FS7 initiation, the control will execute any selected schedule, instead of schedule 10.
NOTICE
STEPPER SCHEDULE TS1-FS7/SS1 TS1-FS11/SS3 INITIATION
A 00 OPEN OPEN TS1-FS3
B 10 CLOSED OPEN TS1-FS3
C 20 OPEN CLOSED TS1-FS3
D 30 CLOSED CLOSED TS1-FS3
Table 7-3. Stepper selection using FS7 and FS11
Table 7-4. Stepper selection using SS1, SS2, SS4, SS8
STEPPER SCHEDULE SS1 SS2 SS4 SS8 INITIATION
A 00 0000TS1-FS3
B 10 1000TS1-FS3
C 20 0100TS1-FS3
D 30 0010TS1-FS3
E 40 0001TS1-FS3
