ENTRON Controls, LLC. • 700120S • Page 155
E-2.1 CONTROL FUNCTIONS
Descriptions and functionality of Control Panel features numbered 1-31 shown in Figure E-1
are found in Section 2.0 Programmable Functions.
POLARITY REVERSE SWITCH (32) – When in default multi-cycle spot welding, this
switch controls the polarity of the first half cycle of a multi-cycle weld. When in HALF CYCLE
mode, this switch can change the polarity of a single 1/2 cycle of weld current. See Section
5.4.7 Process Outputs for details of programming HALF CYCLE operation.
VALVE LEDs – Even though three valves can be programmed, only Valve 1 is available as
an output on this control. Available VALVE codes are indicated in Table E-1.
Table E-1. VALVE codes
EXTERNAL SCHEDULE SELECT (
S.S.S.S.
S.S.S.S.
S.S.=
0101
0101
01) can be programmed but is not available in the
EN1000-B and EN1001-B Controls.
NOTICE
NOTICE
APPENDIX E EN1000/EN1001 BENCH CONTROLS (cont.)
CODE TS1-SV1
00
01 X
02
03 X
04
05 X
06
07 X
