Epson Stylus Pro 9000 - Print Engine User Manual

EPSON Stylus Pro 9000
Appendix 175
PRINTER
MECHANISM
308 1044292 HEAD ADJUSTOR B 1
PRINTER
MECHANISM
309 1044293 CUTTER CAP 1
PRINTER
MECHANISM
310 1044294 SOLONOID SPRING 1
PRINTER
MECHANISM
311 1044295 CUTTER SOLONOID ASSY 1
PRINTER
MECHANISM
312 1044296 CUTTER SPRING 1
PRINTER
MECHANISM
313 1044297 SLIDE ECCENTRIC CAM 2
PRINTER
MECHANISM
314 1044298 SLIDE GEAR 1
PRINTER
MECHANISM
319 1030787
COMPRESSION
SPRING,9.9
2
PRINTER
MECHANISM
402 1044300 CR ROCK ASSY 1
PRINTER
MECHANISM
403 1045666 CAP ASSY. 1
PRINTER
MECHANISM
404 2030410 PUMP MOTOR ASSY 1
PRINTER
MECHANISM
405 1035836 PUMP ASSY. 1
PRINTER
MECHANISM
406 1033209 CLEANER,HEAD,ASP 1
PRINTER
MECHANISM
407 1044302 F BOX R ASSY 1
PRINTER
MECHANISM
411 1035198
MOUNTING
PLATE,MOTOR,ASF
1
Table 7-12. Parts List (continued)
Block Name
Ref
No.
Part Code Description Qty
PRINTER
MECHANISM
412 1012618 DAMPER,CR 3
PRINTER
MECHANISM
413 1038605
PLANE
WASHER,3.3*1.5*8,S/NA
3
PRINTER
MECHANISM
414 1017596 SHAFT,DAMPER,CR;B 3
PRINTER
MECHANISM
415 1037461
FASTEN
PLATE,MOTOR,ASF
1
PRINTER
MECHANISM
503 1044305 I/C COVER 2
PRINTER
MECHANISM
504 1035239 CAM,VALVE 6
PRINTER
MECHANISM
505 1044306 BULB GEAR 2
PRINTER
MECHANISM
506 1044307 BULB ADJUST GEAR L 1
PRINTER
MECHANISM
507 1044308 BULB ADJUST GEAR L 1
PRINTER
MECHANISM
508 1044309 I/H BULB SPRING 2
PRINTER
MECHANISM
509 2030092 INK BOARD ASSY 2
PRINTER
MECHANISM
510 2030093 HODER DETECTOR ASSY 2
PRINTER
MECHANISM
511 2024712 DETECTOR,INK END 6
PRINTER
MECHANISM
512 2030095 HODER L TAPE CABLE 1
PRINTER
MECHANISM
513 2030096 HOLDER R TAPE CABLE 1
Table 7-12. Parts List (continued)
Block Name
Ref
No.
Part Code Description Qty
