Epson Stylus Pro 9000 - Print Engine User Manual

EPSON Stylus Pro 9000
Appendix 176
PRINTER
MECHANISM
514 1044322 I/C LINK 2
PRINTER
MECHANISM
515 1044323 I/C LEVER KNOB 6
PRINTER
MECHANISM
516 2030097 INK ID BOARD ASSY R 2
PRINTER
MECHANISM
517 2030098 INK ID BOARD ASSY C 2
PRINTER
MECHANISM
518 2030099 INK ID BORAD ASSY L 2
PRINTER
MECHANISM
519 1035844 HOLDER ASSY.,VALVE,A 6
PRINTER
MECHANISM
520 2030100 NOT DETECTOR ASSY R 2
PRINTER
MECHANISM
521 2030101 NOT DETECTOR ASSY D 2
PRINTER
MECHANISM
522 2030102 NOT DETECTOR ASSY L 2
PRINTER
MECHANISM
523 1044336 I/H LEVER L 1
PRINTER
MECHANISM
524 1044337 I/H LEVER KNOB L 1
PRINTER
MECHANISM
525 1044338 I/H LEVER R 1
PRINTER
MECHANISM
526 1044339 I/H LEVER KNOB R 1
PRINTER
MECHANISM
527 1044343 BULB KNOB 2
PRINTER
MECHANISM
528 1044344 BULB MANUAL CAM 2
Table 7-12. Parts List (continued)
Block Name
Ref
No.
Part Code Description Qty
PRINTER
MECHANISM
530 1044346 OIL DAMPER 2
PRINTER
MECHANISM
531 1044347 I/H SPACER 4
PRINTER
MECHANISM
532 1044348 I/H IDLE GEAR 2
PRINTER
MECHANISM
533 1044349 LATCH 2
PRINTER
MECHANISM
534 1044350 FRANGE(2 INCH) 2
PRINTER
MECHANISM
535 1044351 FLANGE(3 INCH) 1
PRINTER
MECHANISM
538 1035266 WIRE SPRING,HOLDER,IC 6
PRINTER
MECHANISM
539 1001468 TORSION SPRING,3490 6
PRINTER
MECHANISM
540 1035267 COVER,HOLDER,IC 6
PRINTER
MECHANISM
541 1035843 HOLDER ASSY.,IC,GUIDE 6
PRINTER
MECHANISM
542 1035274 LEVER,INK END 6
PRINTER
MECHANISM
601 2030103 CR BOARD ASSY 1
PRINTER
MECHANISM
602 2030104
HEAD ORIGIN POINT
DETECTOR ASSY
1
PRINTER
MECHANISM
603 2030105 CR ENC ASSY 1
PRINTER
MECHANISM
604 1044355 CR TAPE CABLE 1 1
Table 7-12. Parts List (continued)
Block Name
Ref
No.
Part Code Description Qty
