evertz 3025EMC - Table 7-1: Storage Capacity for 2 Gb Playout Cache

To Next Page

To Previous Page

3025EMC Master Control Switching & Channel Branding

Page 140 Revision 3.0.3

Logo Size Total Pixels

Overture Size Maximum Quantity

Maximum

Animation (sec)

YCbR

format

RGB

Format

YCbR

format

RGB

Format

YCbR

format

RGB

Format

525

1/9

38880

(240×162)

228 152 9206 13808 307 460

87480

(360×243)

513 342 4091 6137 136 205

Full

349920

(720×486)

2050 1367 1023 1534 34 51

625

1/9

46080

(240×192)

270 180 7767 11651 311 466

103680

(360×288)

608 405 3452 5178 138 207

Full

414720

(720×576)

2430 1620 863 1295 35 52

720p

1/9

102480

(427×240)

600 400 3493 5239 116 175

230400

(640×360)

1350 900 1553 2330 52 78

Full

921600

(1280×720)

5400 3600 388 583 13 19

1080i

1/9

230400

(640×360)

1350 900 1553 2330 52 78

518400

(960×540)

3038 2025 690 1036 23 35

Full

2073600

(1920×1080)

12150 8100 173 259 6 9

Table 7-1: Storage Capacity for 2Gb Playout Cache
