evertz 3025EMC - Output; Genlock Source

3025EMC Master Control Switching & Channel Branding
Page 46 Revision 3.0.3
Automation Transition on odd field: This option is only available for 720p/50 and 720p/59.94 video
standards and is for channels that are using Dolby-E. This forces
transitions, DVE Moves and Keyer cuts (with video cut) that are triggered
from automation to start on an odd 625i/525i field (720p frame).

NOTE: The 3G option MUST BE PURCHASED for 1080p video standards to
operate correctly.
4.4.2. Output
This section of the video configuration tab enables users to specific both Horizontal and Vertical
Blanking control. For each of the outputs (PGM, PRV and CLEAN), specific behavior can be set.
Under Horizontal Blanking control, the user can select:
Blanked: Entire horizontal area of video is blanked.
Bypass: Entire horizontal area of video is forwarded untouched by the EMC.
Embedded Audio: Only embedded audio is inserted in the horizontal area and the rest is blanked.
Under Vertical Blanking control, the user can select:
Blanked: Entire vertical area of video is blanked.
Selective Bypass: Selective lines of vertical area of video are forwarded untouched by the EMC.
The lines are selected under the Selective Bypass tab. The remaining vertical area is
blanked.
Bypass: Entire vertical area of video is forwarded untouched by the EMC.

NOTE: When the Video Standard is configured as 525i/59.94 and the PGM
Vertical Blanking control is configured for Selective Bypass an option becomes
available to allow for closed captions on the first line of active video to be
bypassed, i.e. not be corrupted during DVE squeezebacks.
The “Mute on Error” selection will allow users to mute audio if an error is detected. This should be set
to NONE. There are other options for this that will be described later in the manual.
4.4.3. Genlock Source
This parameter enables you to select a genlock source for the EMC.
Backplate: This sets the REF input on the EMC rear plate as the genlock source.
Frame 1: This sets the REF A input on the frame (like 3000FR) as the genlock source.
Frame 2: This sets the REF B input on the frame (like 3000FR) as the genlock source.
