3025EMC Master Control Switching & Channel Branding
Page 56 Revision 3.0.3
3. VANC Blanking – If the bus is configured for blanked in the Vertical Blanking Controls dialogue
of the Video Tab (see section 4.4.2) then the SMPTE 2020 data will pass-through the
3025EMC untouched.
SMPTE 2020 de-embedding will read the data per the channel configuration for DID/SDID regardless
of the input line number.
4.5.2.1. Metadata Inputs
There are eight metadata inputs that can be configured (The Emergency settings are not currently
supported). These are PGM Meta 1, Meta 2, Meta 3 and Meta 4 and also PST Meta , Meta 2, Meta 3
and Meta 4.
4.5.2.2. Metadata Input Source
Metadata Input Source
Description
VANC
If the source for the metadata input needs to be
SMPTE 2020, then this setting should be used. If
Meta 1 input is being configured then the VANC
source will be the metadata that corresponds to
the DID and VANC 1 SDID in the configuration.
For Meta 2 it would be DID and VANC 2 SDID etc.
Decoder 1
Decoder 1 is the metadata output of Decoder 1
which will normally be in the PGM Path.
Decoder 2
Decoder 2 is the metadata output of Decoder 2
which will normally be in the PST Path.
Decoder 3
Not currently supported.
Decoder 4
Not currently supported.
Presets 1 to 8
Not currently supported.
Serial 1 to 4
Not currently supported.
Table 4-3: Metadata I/O Configuration
4.5.2.3. Encoders
There are four encoders that can be configured here, but only encoder one and two are currently
supported. The other encoders are for future use.
4.5.2.4. Output Source
The metadata source that the encoder(s) will be using can be configured here. Normally encoder 1 will
be using Meta 1 and encoder 2 will be using Meta 2.
4.5.2.5. Serial Outputs
Not currently supported.
4.5.2.6. Output Source
Not currently supported.
