3025EMC Master Control Switching & Channel Branding
Page 40 Revision 3.0.3
4.3.2. QMC-Link Address
The QMC-Link Address is required to be set to a value. QMC-Link (QLINK) is a proprietary protocol
that runs on shared serial bus that allows for multiple EMCs to exist on a single bus. This configured
value gives the EMC channel a unique ID (set in HEX notation) in a system with multiple channels.
EMC-Setup will automatically start at 0x00 and increment by 1 for every channel added in the
configuration. The QLINK address must also match the address configured on the EMC. See
section 4.1.
IMPORTANT: There MUST always be a channel configured in the configuration
file with HEX ID 0x00.
4.3.3. Transition Timings
For each of the transition types (Cut, V-Fade, etc) set parameters for each of the four Speeds (Slow,
Medium, Fast, and Custom). The timing will be used later from the manual control panels. The timing
diagram graphic changes for each transition type to assist you in setting the timings.
Type: Enables you to select to the transition type. Types include: Cut, V Fade, Cut-Fade, Mix
and Fade-Cut.
Speed: Enables you to select the speed of the transitions. Speed options include: Slow,
Medium, Fast, and Custom.
Duration: Enables you to set the total duration.
Audio Lead / Audio Lag: Enables you to the set the amount of Audio Lead and Audio Lag.
4.3.3.1. View Table
Selecting this button will open the “Transition Adjustment” window as illustrated in Figure 4-7. This
window enables you to view your current transition details for each transition.
