3025EMC Master Control Switching & Channel Branding
Page 42 Revision 3.0.3
4.3.4. Default Transition
This is the transition type that will be first displayed on a control panel at power up.
4.3.5. Customizations
Add a checkmark to this box to enable “Emergency used for Breakaway Audio” option. This feature is
not currently supported. This option may not appear in the Main Tab.
4.3.6. MC Board Type
This parameter displays the board type currently in use and should be EMC3025.
Single Panel Control: Add a checkmark to this box to enable “Single Panel Control.”
In a multiple panel control system the “Single Panel Control” option configures the channel that only a
single panel can control that channel at any time. This function operates in a most recent request
mode, i.e. the panel that most recently selected this channel will have control and all other panels will
no longer have control of this channel.
4.3.7. Options
Flip Flop: Enables you to select Bus, Keyers, and Overs to flip flop. If flip-flop is selected for the
bus, then the Preset bus will change (after the transition) to the source on the Program
bus before the transition. If flip-flop is selected for Keyers and Overs, they will change
after the transition has finished such that a keyer/voice-over going to On-Air will be
ready to come back to the Preset state at the next transition.
Please note: Bus Flip-Flop will NOT occur if the transition was started by M2100
Automation.
Please note: The Keyer Flip-Flop setting takes priority over the Keyer “Hold
Trans. Level” setting (see the Keyer configuration tab).
A/B Mode: When not in A/B Mode (normal mode), the Program Output will be routed from the
Program Input and the Preset Output will be routed from the Preset Input (assuming that
the Background Level is On and the EMC is not in transition). In A/B Mode the EMC will
flip-flop between A/B Mode (PGM In→PGM Out, PST In→PST Out) and B/A Mode
(PST In→PGM Out, PGM In→PST Out) after a transition. This mode is normally used
when there are issues with the switching of the upstream router or there are conversion
modules directly upstream of the EMC PGM/PST inputs.
Auto-select Background Level: With this option enabled the Background Level will be enabled
automatically when the Program and Preset sources are different.
Auto-select Keyer Enable: With this option enabled the Keyer Transition Enable state will be
enabled automatically when a Keyer is preset (level is enabled).
