3025EMC Master Control Switching & Channel Branding
Page 14 Revision 3.0.3

Note: The EMC module REQUIRES 3 slots in any of the available frames.
A slot
blocker is installed on the module to prevent installation of other modular products.
2.8.1. 3025EMC-IO-DIN
The 3025EMC-IO-DIN uses DIN 1.0/2.3 connectors for the video and audio connections.
2.8.2. 3025EMC-IO-XLINK
The 3025EMC-IO-XLINK uses an Evertz XLINK connector for the main video inputs. The 3025EMC-IO-
XLINK uses DIN 1.0/2.3 connectors for the remaining video and audio connections.

Note: The XLINK cable to use for the 3025EMC-IO-XLINK is XLINK-BHP-5-EQX1FR
.
Contact factory for assistance if you are using XLINK.
2.8.3. 3025EMC-IO-BNC
The 3025EMC-IO-BNC uses BNC per IEC 61169-8 Annex A connectors for the video and audio
connections.
2.9. INTERFACE DEFINITIONS
The section describes the IO connections on the various EMC rear plates. Specific differences will be
highlighted.
