3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 141
Logo Size Total Pixels Overture Size Maximum Quantity
Maximum
Animation (sec)
YCbR
format
RGB
Format
YCbR
format
RGB
Format
YCbR
format
RGB
Format
525
1/9
38880
(240×162)
228 152 36822 55234 1227 1841
1/4
87480
(360×243)
513 342 16366 24548 546 818
full
349920
(720×486)
2050 1367 4091 6137 136 205
625
1/9
46080
(240×192)
270 180 31069 46603 1243 1864
1/4
103680
(360×288)
608 405 13808 20713 552 829
full
414720
(720×576)
2430 1620 3452 5178 138 207
720p
1/9
102480
(427×240)
600 400 13970 20955 466 699
1/4
230400
(640×360)
1350 900 6214 9321 207 311
full
921600
(1280×720)
5400 3600 1553 2330 52 78
1080i
1/9
230400
(640×360)
1350 900 6214 9321 207 311
1/4
518400
(960×540)
3038 2025 2762 4143 92 138
full
2073600
(1920×1080)
12150 8100 690 1036 23 35
Table 7-2: Storage Capacity for 8 Gb Playout Cache
7.1.2. Primer on Creating Logos
The 3025EMC hardware executes the keying and display of logos, however, the user is responsible for
composing the image design. Unfortunately, the image created by the artist is not always generated
the same when it is keyed into and displayed on the video. These following sections will introduce the
user to some basic principles associated with keying graphical information on video. It will also provide
some guidelines when preparing logos to get the best quality possible.
Evertz Overture™ software imports the user’s image, formats it, and sends it to the EMC hardware. If
the user is already familiar with the creating images for use on video, please refer to the summary in
section 7.1.2.9 for a brief overview.
