3025EMC Master Control Switching & Channel Branding
Page 66 Revision 3.0.3
There is also the option to assign “same buss” as the input source. This forces the input for this channel
to come from the same bus to which the shuffle store has been applied.

Please note: Shuffle Stores must be saved when configuration of each store is
completed. If not then changes will be lost.
4.8. KEYER
Figure 4-23: Keying Levels Tab
