3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 79
4.11.1. AP Board Configuration
No AP Board (Default): With this configured none of the 3025AP module setting will be exposed
to the user.
Zero Module AP: With this configured the Dolby-E decoder and encoder settings are not
exposed to the user. The Additional Options (Upmix, Downmix and
Intelligain) do become available. As each additional option is checked the
configuration options for each become exposed to the user.
Four Module AP: With this configured the Dolby-E decoder and encoder settings are now
exposed to the user. The Additional Options (Upmix, Downmix and
Intelligain) do become available. As each additional option is checked the
configuration options for each become exposed to the user.
Eight Module AP: The eight Dolby-E module option (4 encode and 4 decode) is not
currently available.
4.11.1.1. Dolby-E Decode Module Config
Module: Use the drop-down menu to select if Module 1 or Module 2 is being
configured.
State: Select if the Module is present (on) or not present (off).
IMPORTANT: For Dolby-E decoded audio to transition correctly modules
enabled, i.e. there must be a Dolby-E decoder in both the PGM and PST input paths.
Source Input Bus: Select if the Dolby-E source for Decoder Module 1/Module 2 will be from
the Program Bus or the Preset Bus.
NOTE: For normal operation, Module 1 should be configured for PGM and Module 2
should be configured for PST.
Source Input Pair: Select on which audio pair of the PGM/PST input embedded audio the
Dolby-E will be present on the input to the EMC.
Destination Audio Start: Configure on which pair the decoded audio will start.
Destination Pairs: Configure how many pairs of the decoded audio will be used. For
example, 5.1+2 would be 4 pairs.
