9. APPLICATION NOTES
9.1. CONTOROL PANEL KEY TYPES
TYPE
NUMBER
FUNCTION
OTHER OPTIONS
Lock
Panel Lock
Lock ALL buttons on
the control panel.
N/A
Aux Lock
Lock the Bus Route
key types
Last Menu
Last Menu
N/A
N/A
Menu
Menu Number
Select the Primary
Menu
Legend: Maximum of 10
characters. 5 top row and 5
bottom row.
Secondary Menu
Menu Number
Select the Primary
Menu
Legend: Maximum of 10
characters. 5 top row and 5
bottom row.
Enable
N/A
With this key
configured in a menu
user will
be unable to
route the PGM and
PST bus unless this
key is held.
N/A
Learn Mode
N/A
Allows the user to re-
programme PGM/PST
source
s when this key
is used
with the
“Source Preset” key.
N/A
Automation On/Off
N/A
Toggles M2100
automation control of
the EMC between
enabled and disabled.
N/A
Bypass Toggle
N/A
Toggles the status of
the PGM O/P 1 and
CLN O/P 1 bypass
relays.
N/A
Channel
Channel Name
Selects the currently
controlled channel.
N/A
Market Key
Market
Put the panel in a
mode that allows for
multiple channels to be
controlled at the same
time.
N/A
Channel Preset
Not Supported
Current
Channel Display
N/A
Displays the channel
that is currently being
controlled by the panel.
N/A
