3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 177
Channel Parking
N/A
This is a LOCAL
disable button. When
pressed the key will
change to red and all
non-
menu keys will be
disabled. This c
an be
removed by selecting
any channel or market.
N/A
Channel Protect
Protect Current
Channel
This is a GLOBAL
disable button. When
pressed the key on the
local panel will change
to red and the
corresponding button
on all other Ethernet
control panels will
change to orange.
ONLY the local channel
will have control over
the specific channel all
other panels will have
no control over the
channel. This can be
removed by either
PRESSING the
channel protect button
on the local channel
(red) or HOLDING
down the channel
protect button on any
other panel (orange).
N/A
GPI/O Lock
N/A
Lock the GPI/Os while
this setting is active.
N/A
GPI/O Toggle
EMC GPI & EMC GPO
DCP GPI & DCP GPO
See Section 9.2 for
more details.
Only available on QMC-DCP &
EMC-DCP.
GPI/O Assert
EMC GPI & EMC GPO
DCP GPI & DCP GPO
See Section 9.2 for
more details.
Only available on QMC-DCP &
EMC-DCP.
GPO Activate
EMC GPO & DCP
GPO
See Section 9.2 for
more details.
Only available on QMC-DCP &
EMC-DCP.
GPI Tally
EMC GPI & DCP GPI
See Section 9.2 for
more details.
Only available on QMC-DCP &
EMC-DCP.
On-Air Enabled
N/A
Route PGM sources
when using
“Preset/Program
Source” key type.
Without this button held-down
only preset
sources can be
changed using
Preset/Program Source” key
type.
