Falcon M-Class | User Guide
238
4.17.4 MSTI Priority Configuration
The user is allowed to inspect the current STP MSTP bridge instance priority configurations and
possibly change them as well
Figure 4-132: STP MSTI Priority Configuration
Table 4-126: STP MSTI Priority Configuration Parameters
The bridge instance (group of VLANs).
The CIST is the
default
instance, which is always active.
Controls the bridge priority
Lower numeric values have better priority.
The bridge priority plus the MSTI instance number, concatenated with
the 6-byte MAC address of the switch forms a Bridge Identifier.
Save:
Click to save changes.
Reset:
Click to undo any changes made locally and revert to previously saved
values.
