Refresh: Refreshes the displayed table starting from the input fields.
Auto-refresh : Automatic refresh occurs every 3 seconds
.<<: Updates the table starting from the first entry in the MLD Group
Table
>>: Updates the table, starting with the entry after the last entry
currently displayed.
4.18.12 MLD SFM Information
Entries in the MLD SFM Information Table are shown on this page. The MLD SFM (Source-Filtered
Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This
table is sorted first by VLAN ID, then by group, and then by Port. Different source addresses belong
to the same group are treated as single entry.
Navigating the MLD SFM Information Table
Each page shows up to 99 entries from the MLD SFM Information table, default being 20, selected
through the "entries per page" input field. When first visited, the web page will show the first 20
entries from the beginning of the MLD SFM Information Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the
MLD SFM Information Table. Clicking the Refresh button will update the displayed table starting
from that or the closest next MLD SFM Information Table match. In addition, the two input fields
will - upon a Refresh button click - assume the value of the first displayed entry, allowing for
continuous refresh with the same start address.
The >> will use the last entry of the currently displayed table as a basis for the next lookup. When
the end is reached the text "No more entries" is shown in the displayed table.
Use the << button to start over.
Figure 4-150: MLD SFM Information
Table 4-144: MLD SFM Information Parameters
