FibroLAN Falcon-MX User Manual

Falcon M-Class | User Guide
364
Buttons
Save: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
4.32.2 Detailed UDLD Status forPort 1
This section displays the UDLD status of the selected port
Figure 4-220: UDLD Status for Port 1
Table 4-193: UDLD Status for Port 1 parameters
Detailed UDLD Port Status
UDLD Admin State
The current port state of the logical port, Enabled if any of
state(Normal,Aggressive) is Enabled.
Device ID (local)
The ID of Device.
Device Name
(local)
Name of the Device
Bidirectional State
The current state of the port.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the
page at regular intervals.
Refresh: Click to refresh this section immediately
