FibroLAN Falcon-MX User Manual

Falcon M-Class | User Guide
121
4.9.5 EVC Configuration
This section displays current EVC configurations. The settings can also be configured here
Figure 4-66: EVC Configuration displays
Table 4-63: EVC Parameters
EVC Configuration
NNI Ports
The list of Network to Network Interfaces for the EVC
EVC Parameters
EVC ID
The EVC ID identifies the EVC. The range is from 1 through 128.
VID
The VLAN ID in the PB network. It may be inserted in a C-tag, S-tag or
S-custom tag depending on the NNI port VLAN configuration. The
range is from 1 through 4095.
IVID
The Internal/classified VLAN ID in the PB network. The range is from 1
through 4095.
