Falcon M-Class | User Guide
413
Each page shows up to 99 entries from the Event table, default being 20, selected through the "entries
per page" input field. When first visited, the web page will show the first 20 entries from the beginning
of the Event table
The "Start from Event Index and Log Index" allows the user to select the starting point in the Event
table. Clicking the Refresh button will update the displayed table starting from that or the next closest
Event table match.
The >>will use the last entry of the currently displayed entry as a basis for the next lookup
When the end is reached the text "No more entries" is shown in the displayed table.
Use the <<: button to start over.
5.10.2 RMON Event Overview
This section provides an overview of RMON Event table entries.
Each page shows up to 99 entries from the Event table, default being 20, selected through the
"entries per page" input field.
When first visited, the web page will show the first 20 entries from the beginning of the Event table
The first displayed will be the one with the lowest Event Index and Log Index found in the Event
table.
The "Start from Event Index and Log Index" allows the user to select the starting point in the Event
table. Clicking the Refresh button will update the displayed table starting from that or the next
closest Event table match.
The >>will use the last entry of the currently displayed entry as a basis for the next lookup
When the end is reached the text "No more entries" is shown in the displayed table.
Use the <<: button to start over.
Figure 5-38: Rmon Event Overview
Table 5-34: Rmon Alarm Overview Parameters
RMON Event Overview
Event Index
Indicates the index of the event entry.
Log Index
Indicates the index of the log entry.
Log Time
Indicates Event log time
Log Description
Indicates the Event description
